多股細絞成束裸銅絲
特制無鹵混合環保材料絕緣
特制無鹵混合環保材料護套
產品應用：
喬浦HLKMC非屏蔽控制電纜用于工業自動化，機電成套設備，機床等機械設備，物流傳輸系統，生產線等控制系統中電氣連接，特別適合用于工業環境中，干燥或者潮濕的室內固定安裝，也可用于非連續往復運動無強制牽引的移動安裝。該線纜具有良好的柔軟性。護套采用低煙無鹵材料，適用于人員密集的具有環保要求的場合，如機場，火車站，商業樓宇，醫院等公共場所。燃燒后低煙，阻燃等級更高，更加安全。當外部有電磁干擾時推薦使用帶屏蔽線纜喬浦HLKMC-S系列產品。
| 型號 | 芯線根數+導體截面積 | 電纜近似外徑 (mm Max.) |
電纜近似重量 (kg / km) |
| HLKMC-0.5-2C | 2*0.5 | 5.7 | 46.3 |
| HLKMC-0.5-3C | 3*0.5 | 6.1 | 55.1 |
| HLKMC-0.5-4C | 4*0.5 | 6.7 | 67.4 |
| HLKMC-0.5-5C | 5*0.5 | 7.5 | 80.8 |
| HLKMC-0.5-6C | 6*0.5 | 8.2 | 94.9 |
| HLKMC-0.5-7C | 7*0.5 | 8.2 | 104.0 |
| HLKMC-0.5-8C | 8*0.5 | 8.9 | 118.4 |
| HLKMC-0.5-9C | 9*0.5 | 9.9 | 136.4 |
| HLKMC-0.5-10C | 10*0.5 | 10.7 | 155.2 |
| HLKMC-0.5-12C | 12*0.5 | 11.0 | 174.9 |
| HLKMC-0.5-14C | 14*0.5 | 11.7 | 198.3 |
| HLKMC-0.5-16C | 16*0.5 | 12.4 | 222.9 |
| HLKMC-0.5-18C | 18*0.5 | 13.1 | 248.3 |
| HLKMC-0.5-20C | 20*0.5 | 13.5 | 268.8 |
| HLKMC-0.5-21C | 21*0.5 | 13.9 | 283.5 |
| HLKMC-0.5-24C | 24*0.5 | 15.6 | 333.5 |
| HLKMC-0.5-25C | 25*0.5 | 16.0 | 348.9 |
| HLKMC-0.5-27C | 27*0.5 | 16.0 | 363.8 |
| HLKMC-0.5-30C | 30*0.5 | 16.6 | 398.3 |
| HLKMC-0.5-32C | 32*0.5 | 17.3 | 428.3 |
| HLKMC-0.5-36C | 36*0.5 | 18.0 | 471.0 |
| HLKMC-0.75-2C | 2*0.75 | 6.2 | 56.8 |
| HLKMC-0.75-3C | 3*0.75 | 6.6 | 68.4 |
| HLKMC-0.75-4C | 4*0.75 | 7.3 | 84.2 |
| HLKMC-0.75-5C | 5*0.75 | 8.1 | 101.3 |
| HLKMC-0.75-6C | 6*0.75 | 8.9 | 119.3 |
| HLKMC-0.75-7C | 7*0.75 | 8.9 | 131.4 |
| HLKMC-0.75-8C | 8*0.75 | 9.7 | 149.6 |
| HLKMC-0.75-9C | 9*0.75 | 10.8 | 172.3 |
| HLKMC-0.75-10C | 10*0.75 | 11.6 | 195.9 |
| HLKMC-0.75-12C | 12*0.75 | 12.0 | 221.7 |
| HLKMC-0.75-14C | 14*0.75 | 12.7 | 252.0 |
| HLKMC-0.75-16C | 16*0.75 | 13.5 | 283.7 |
| HLKMC-0.75-18C | 18*0.75 | 14.3 | 316.4 |
| HLKMC-0.75-20C | 20*0.75 | 14.7 | 343.2 |
| HLKMC-0.75-21C | 21*0.75 | 15.1 | 362.0 |
| HLKMC-0.75-24C | 24*0.75 | 17.0 | 425.1 |
| HLKMC-0.75-25C | 25*0.75 | 17.4 | 444.7 |
| HLKMC-0.75-27C | 27*0.75 | 17.4 | 464.9 |
| HLKMC-0.75-30C | 30*0.75 | 18.1 | 509.7 |
| HLKMC-0.75-32C | 32*0.75 | 18.9 | 547.8 |
| HLKMC-0.75-36C | 36*0.75 | 19.7 | 603.5 |
| HLKMC-1.0-2C | 2*1.0 | 6.6 | 66.7 |
| HLKMC-1.0-3C | 3*1.0 | 7.1 | 81.8 |
| HLKMC-1.0-4C | 4*1.0 | 7.8 | 100.2 |
| HLKMC-1.0-5C | 5*1.0 | 8.7 | 120.8 |
| HLKMC-1.0-6C | 6*1.0 | 9.5 | 142.5 |
| HLKMC-1.0-7C | 7*1.0 | 9.5 | 157.4 |
| HLKMC-1.0-8C | 8*1.0 | 10.4 | 179.4 |
| HLKMC-1.0-9C | 9*1.0 | 11.6 | 206.5 |
| HLKMC-1.0-10C | 10*1.0 | 12.4 | 234.6 |
| HLKMC-1.0-12C | 12*1.0 | 12.9 | 266.3 |
| HLKMC-1.0-14C | 14*1.0 | 13.6 | 303.2 |
| HLKMC-1.0-16C | 16*1.0 | 14.5 | 341.8 |
| HLKMC-1.0-18C | 18*1.0 | 15.3 | 381.4 |
| HLKMC-1.0-20C | 20*1.0 | 15.8 | 414.3 |
| HLKMC-1.0-21C | 21*1.0 | 16.2 | 436.9 |
| HLKMC-1.0-24C | 24*1.0 | 18.2 | 512.6 |
| HLKMC-1.0-25C | 25*1.0 | 18.7 | 536.1 |
| HLKMC-1.0-27C | 27*1.0 | 18.7 | 561.4 |
| HLKMC-1.0-30C | 30*1.0 | 19.5 | 616.1 |
| HLKMC-1.0-32C | 32*1.0 | 20.3 | 662.0 |
| HLKMC-1.0-36C | 36*1.0 | 21.2 | 730.3 |
| HLKMC-1.5-2C | 2*1.5 | 7.7 | 92.3 |
| HLKMC-1.5-3C | 3*1.5 | 8.2 | 112.8 |
| HLKMC-1.5-4C | 4*1.5 | 9.1 | 140.0 |
| HLKMC-1.5-5C | 5*1.5 | 10.1 | 169.2 |
| HLKMC-1.5-6C | 6*1.5 | 11.2 | 199.8 |
| HLKMC-1.5-7C | 7*1.5 | 11.2 | 221.3 |
| HLKMC-1.5-8C | 8*1.5 | 12.2 | 252.4 |
| HLKMC-1.5-9C | 9*1.5 | 13.6 | 290.6 |
| HLKMC-1.5-10C | 10*1.5 | 14.6 | 330.4 |
| HLKMC-1.5-12C | 12*1.5 | 15.2 | 375.8 |
| 型號 | 芯線根數+導體截面積 | 電纜近似外徑 (mm Max.) |
電纜近似重量 (kg / km) |
| HLKMC-1.5-14C | 14*1.5 | 16.1 | 428.4 |
| HLKMC-1.5-16C | 16*1.5 | 17.1 | 483.4 |
| HLKMC-1.5-18C | 18*1.5 | 18.1 | 539.8 |
| HLKMC-1.5-20C | 20*1.5 | 18.6 | 586.9 |
| HLKMC-1.5-21C | 21*1.5 | 19.1 | 619.1 |
| HLKMC-1.5-24C | 24*1.5 | 21.6 | 726.4 |
| HLKMC-1.5-25C | 25*1.5 | 22.1 | 759.9 |
| HLKMC-1.5-27C | 27*1.5 | 22.1 | 796.5 |
| HLKMC-1.5-30C | 30*1.5 | 23.0 | 874.6 |
| HLKMC-1.5-32C | 32*1.5 | 24.0 | 939.9 |
| HLKMC-1.5-36C | 36*1.5 | 25.0 | 1037.6 |
| HLKMC-2.5-2C | 2*2.5 | 9.2 | 137.6 |
| HLKMC-2.5-3C | 3*2.5 | 9.9 | 169.9 |
| HLKMC-2.5-4C | 4*2.5 | 11.0 | 211.8 |
| HLKMC-2.5-5C | 5*2.5 | 12.2 | 256.8 |
| HLKMC-2.5-6C | 6*2.5 | 13.5 | 303.8 |
| HLKMC-2.5-7C | 7*2.5 | 13.5 | 337.8 |
| HLKMC-2.5-8C | 8*2.5 | 14.7 | 385.7 |
| HLKMC-2.5-9C | 9*2.5 | 16.4 | 443.8 |
| HLKMC-2.5-10C | 10*2.5 | 17.7 | 504.5 |
| HLKMC-2.5-12C | 12*2.5 | 18.3 | 575.9 |
| HLKMC-2.5-14C | 14*2.5 | 19.4 | 657.7 |
| HLKMC-2.5-16C | 16*2.5 | 20.7 | 743.0 |
| HLKMC-2.5-18C | 18*2.5 | 21.9 | 830.5 |
| HLKMC-2.5-20C | 20*2.5 | 22.6 | 904.3 |
| HLKMC-2.5-21C | 21*2.5 | 23.2 | 954.0 |
| HLKMC-2.5-24C | 24*2.5 | 26.1 | 1118.6 |
| HLKMC-2.5-25C | 25*2.5 | 26.8 | 1170.2 |
| HLKMC-2.5-27C | 27*2.5 | 26.8 | 1228.5 |
| HLKMC-2.5-30C | 30*2.5 | 27.9 | 1350.4 |
| HLKMC-2.5-32C | 32*2.5 | 29.1 | 1451.2 |
| HLKMC-2.5-36C | 36*2.5 | 30.4 | 1604.0 |
| HLKMC-4.0-2C | 2*4.0 | 11.0 | 199.4 |
| HLKMC-4.0-3C | 3*4.0 | 11.8 | 247.7 |
| HLKMC-4.0-4C | 4*4.0 | 13.1 | 309.9 |
| HLKMC-4.0-5C | 5*4.0 | 14.6 | 376.4 |
| HLKMC-4.0-7C | 7*4.0 | 16.1 | 497.0 |
| HLKMC-6.0-2C | 2*6.0 | 12.6 | 271.8 |
| HLKMC-6.0-3C | 3*6.0 | 13.5 | 340.1 |
| HLKMC-6.0-4C | 4*6.0 | 15.1 | 427.0 |
| HLKMC-6.0-5C | 5*6.0 | 16.8 | 519.6 |
| HLKMC-6.0-7C | 7*6.0 | 18.5 | 688.8 |
| HLKMC-10.0-3C | 3*10 | 17.5 | 567.6 |
| HLKMC-10.0-4C | 4*10 | 19.6 | 713.4 |
| HLKMC-10.0-5C | 5*10 | 21.8 | 869.0 |
| HLKMC-10.0-7C | 7*10 | 24.1 | 1153.6 |
| HLKMC-16-3C | 3*16 | 19.8 | 804.0 |
| HLKMC-16-4C | 4*16 | 22.1 | 1017.2 |
| HLKMC-16-5C | 5*16 | 24.6 | 1243.1 |
| HLKMC-16-7C | 7*16 | 27.2 | 1661.1 |
| HLKMC-25-3C | 3*25 | 24.8 | 1249.0 |
| HLKMC-25-4C | 4*25 | 27.7 | 1580.6 |
| HLKMC-25-5C | 5*25 | 30.9 | 1932.2 |
| HLKMC-25-7C | 7*25 | 34.2 | 2583.2 |
| HLKMC-35-3C | 3*35 | 27.8 | 1652.2 |
| HLKMC-35-4C | 4*35 | 31.0 | 2097.0 |
| HLKMC-35-5C | 5*35 | 34.6 | 2567.3 |
| HLKMC-35-7C | 7*35 | 38.4 | 3442.2 |
| HLKMC-50-3C | 3*50 | 33.3 | 2354.3 |
| HLKMC-50-4C | 4*50 | 37.2 | 2988.4 |
| HLKMC-50-5C | 5*50 | 41.5 | 3659.2 |
| HLKMC-50-7C | 7*50 | 46.0 | 4907.3 |
| HLKMC-70-3C | 3*70 | 37.8 | 3143.3 |
| HLKMC-70-4C | 4*70 | 42.2 | 3998.1 |
| HLKMC-70-5C | 5*70 | 47.2 | 4900.1 |
| HLKMC-95-3C | 3*95 | 43.8 | 4250.0 |
| HLKMC-95-4C | 4*95 | 49.0 | 5408.7 |
| HLKMC-95-5C | 5*95 | 54.7 | 6631.2 |
| HLKMC-120-3C | 3*120 | 48.3 | 5262.4 |
| HLKMC-120-4C | 4*120 | 54.0 | 6703.8 |
| HLKMC-150-3C | 3*150 | 53.5 | 6527.9 |
| HLKMC-150-4C | 4*150 | 59.9 | 8320.5 |
| HLKMC-185-4C | 4*185 | 66.6 | 10268.4 |
